75F® SMART VAV CONTROLLER
SAVE ENERGY. IMPROVE AIRFLOW. MAXIMIZE COMFORT.
A Smart Variable Air Volume (VAV) controller is an advanced building automation system that is designed to regulate the airflow in the HVAC systems of large commercial or industrial buildings. The 75F Smart VAV Controller efficiently integrates with other building systems to optimize HVAC airflow and temperature helping deliver energy efficiency, occupant comfort, and air quality.
75F® ACTUATOR™
| Torque Motor | 5Nm |
| Operating Range Y | 0.5 – 10V |
| Position Accuracy | +/- 5% |
MECHANICAL
I/O
A. (2) Thermistor Inputs 10K Type 2
B. (2) 0-10V dc analog inputs.
A. (2) 0-10V DC or 4-20mA Analog Outputs
B. (2) relays rated at 1A, 120V ac or 24 V ac/dc resistive load
ELECTRICAL
24V AC/DC (+/-15%) with nominal power consumption of 1.0W
and maximum consumption of 2.5W
MECHANICAL
ELECTRICAL
Supply voltage over a One Wire interface powered at 3.3V
with maximum current limit of 10mA
COMMUNICATIONS
75F One Wire Protocol
MECHANICAL
Humidity 20-85% Non-condensing;
Temperature 0°F to 122°F (-17°C to 50°C)
COMMUNICATION
